X.Y working size |
250mm×250mm |
Z working size |
90mm- (110mm if u need Rotary device) |
The Max width of the workpiece |
400mm |
The Max length of the workpiece |
Unlimited |
Speed of working |
0-4000mm/min |
Speed of spindle |
6000-24000RMP |
Spindle power |
1500W (Water-Cooling Motor) |
Taper sleeve |
3.175mm(1/8"), 4mm (1/6") and 6mm (1/4") |
Operating system |
Mach3 / DSP Controller / NCSTUDIO |
File form |
It supports G-code,CAD/CAM,Artcam / Cascate / Proe /Artgrave / Type3/Artcut, etc... |
Resolution of software |
0.001mm |
Resolution of machine |
0.02mm |
Positioning accuracy |
0.06mm/300mm |
Repeat accuracy |
0.02mm |
Voltage |
220V-50HZ |
Optional devices |
Rotary device; Vacuum hold down table, High precision Vise, etc... |
